Frameless door- Frameless door
Lock- Lock
Black Display Cooler
SCU1425 FRAMELESS
Item no.: 53321(Substitution for 17044 SCU1425 FRAMELESS)
Brand: TEFCOLD
- Frameless glass door
- Elegant design
- Black interior and exterior
- Extra high glass door
- Great product presentation
- Internal vertical and horizontal LED light
- Fan assisted cooling
Technical specifications
Measures and Content
- Temperature Range+2 to +10 °C
- Climate Class4
- Gross / Net Weight87.5 / 77.5 kg
- Gross / Net Volume387 / 347 l
- Cans 330 ml441 pcs
- Cans 500 ml308 pcs
- Bottles 330 ml272 pcs
- Bottles 500 ml PET238 pcs
Design and Material
- Feet / Legs2 adjustable feet
- Castors2 rollers
- Exterior FinishBlack
- Interior FinishBlack ABS
- Interior LightLED inside door frame
- Lock
- Door No & Type1 hinged glass door
- Door ReversibleNo
- Shelves No & Type5 black sheet metal
- Shelf ColorBlack
- Shelf Dimensions492 x 405 mm
- Max load on Shelves196 kg/m²
Cooling and Functions
- Type of ControllerMechanical
- Type of CoolingFan assisted
- Type of DefrostAutomatic
- RefrigerantR600a
- Refrigerant Charge85 g
- Thermometer
Power and Consumption
- Energy ClassD
- EPREL No575918
- Max Ambient30°C at 55% RH
- Energy Consumption1.87 kWh/24h
- Annual Energy Cons.683 kWh/year
- Input Power235 W
- Voltage / Frequency220-240/50 V/Hz
- Noise Level45 dB(A)
Dimensions
- Internal Dimension (WxDxH)505 x 462 x 1742 mm
- External Dimension (WxDxH)595 x 595 x 1990 mm
- Packed Dimension (WxDxH)665 x 715 x 2150 mm
- 40ft Container Load 54 pcs
- GTIN / EAN5708181737429
Downloads
Description
Spare parts
- 02
Item no. 15347Cover For Ballast - 03
Item no. 15629LED Power Supply 12 V 35 W - 04Item no. 33332Condenser
- 05
Item no. 14199Holder For Condenser 2015 - 06Item no. 33333Cover For Wires
- 07
Item no. 16642Top Hinge Right - 08
Item no. 13531Fan Motor Int/Ext - 09Item no. 33334Cover For Internal Fan Black
- 10
Item no. 13998Thermostat K50B-S16176 R600 - 11
Item no. 14014Thermostat Knob - 12Item no. 33379Digital Thermometer w/Black Frame
- 13
Item no. 33336Light Switch Black - 14
Item no. 32062Clip For Shelf Black - 15Item no. 33337Rail For Shelves Black 1374 mm.
- 16
Item no. 33338460 mm LED Strip 6500K 7LM - 17
Item no. 33339LED Cover - 18
Item no. 33340End Cap LED Light Black - 19Item no. 33341Roll Bond Evaporator Black
- 20Item no. 68858Metal Sheet Shelf Black
- 21Item no. 54433Bottom Hinge Right
- 22
Item no. 33342Bottom Panel Hexagonal - 23
Item no. 11243Cover For Screw - 24
Item no. 10715Lock With Keys - 25
Item no. 14565Adjustable Foot - 26Item no. 11238Rear Grill Black
- 27Item no. 14198Fixing Clamp For Condenser
- 28
Item no. 11470Drip Tray - 29
Item no. 14614Pin For Big Roller - 30Item no. 14607Big Plastic Roller
- 31Item no. 13610Cable Clamp
- 32Item no. 33343Compressor TT1117GY R600a
- 34
Item no. 15721Filter Drier 20 G - 35
Item no. 11442Drain Pipe - 39
Item no. 33344Door Gasket Black - 42Item no. 33345Frameless Door Complete
- 42Item no. 54008Frameless Door Complete L/H
- 43
Item no. 154871200 mm LED Strip 6500K 7LM - 44
Item no. 12820Door Spring Right - 45
Item no. 12852Bottom Hinge Right - 46
Item no. 12875Hinge Spring Cover
